I finally understand the old problem of trying to balance accessing the internet and leaving the telephone line open for phone calls, and how it was eventually resolved.
The basis of the problem is the fact that there is a single physical copper line coming into the household. With a single line we were limited to sending information from one end to the other – think of the switchboard operator who would have to manually connected two lines!
Eventually the operator was put out of a job by automatic exchanges which provided the first dial tone. Still we had the problem that a single line could only be used to transmit a single signal at a time.
In comes multiplexing! We have a limited resource, the telephone line, which we want to share so the concept of multiplex was created where the shared resource was split up but everyone who used it had no idea others might also be using the line.
There are many types of multiplexing:
- Synchronous Time-Division Multiplexing (STDM)
- Frequency-Division Multiplexing (FDM)
- Statistical Multiplexing
STDM is one of the more basic ideas, where time is simply broken up and assigned in a round-robin style to everyone who wants to use the line, i.e. so maybe I only use the line every X milliseconds.
FDM is slightly more complex and something you will recognize as one of the solutions implemented so us nerds could continue to connect to the internet. The idea is that your voice and hearing has a very specific range, outside of that you can’t hear – think dog whistle.
So the brilliant idea was that there is a huge amount of frequencies that are being left out, and that if we transmitted our packets in another bands, that we could actually transmit both together. So again we would divide up the allocated frequency band by the number of users who wanted to use it and restrict them to send on those.
When DSL broadband came in you needed to go around to all the phones in the house and add a DSL filter to the line, to split out these frequencies to ensure as the phones would not know what to deal with all this extra information coming in at these higher frequencies.
This works up to a the point you want to scale the system, which is why we have have statistical multiplexing. This is based off STDM, but sets an upper bound on the the time it is allocated and is the origin of the network packet! Now messages would be broken up into these specific sized network packets and at the line each packet is assessed on a packet-by-packet basis to prioritize them.
This is all the responsibility of the physical layer in the network protocol stack, though it is only one of many of it’s responsibilities! More to come…
